- Quick Config - Quick Configuration of active SilverNet Devices
- Quick configuration of your SilverNet radios is made simple with our Quick Config tool
- Statistics - Live Statistic Updates of all active Devices
- Live Statistics on all devices being monitored
- SilverTest - Built in data speed tester to test the quality and throughput of a link
- SilverTest Built in datatester
-
73208P SERIES 7 - INDUSTRIAL UNMANAGED NETWORK SWITCH 8 PORT POE+ WITH 2 SFP PORTS
04 Mar 2025 SilverNet- 8 x 10/100/1000Base-T
- 2 x 1000Base-FX
- 20Gbps bandwidth
- IEEE803.af/at compliant PoE+
- RJ45 supports auto MDI/MDI-X function
- Auto negotiation speed, half/full-duplex
- Store and forward
- Max packet size: 10kbytes
- Wide range power design ( 12~56VDC )
- Operating temperature (-40 ̊C ~ +75 ̊C)
- Reverse polarity protection
- Resettable fuse to protect against overcurrent
- IP-40 protection
- EFT protection for power line
- Ethernet ESD protection
- DIN rail and Wall mounted installation
-
73208P-BT SERIES 7 - INDUSTRIAL UNMANAGED NETWORK SWITCH 8 PORT POE++ WITH 2 SFP PORTS
04 Mar 2025 SilverNet- 8 x 10/100/1000Base-T
- 2 x 1000Base-FX
- 20Gbps bandwidth
- IEEE803.af/at/bt compliant
- RJ45 supports auto MDI/MDI-X function
- Auto negotiation speed, half/full-duplex
- Store and forward
- Max packet size: 10kbytes
- Wide range power design ( 12~56VDC )
- Operating temperature (-40 ̊C ~ +75 ̊C)
- Reverse polarity protection
- Resettable fuse to protect against overcurrent
- IP-40 protection
- EFT protection for power line
- Ethernet ESD protection
- DIN rail and Wall mounted installation
-
- 24 x 10/100/1000M Base-TX RJ45 Ports
- 4 x Gigabit SFP Ports
- Auto Negotiation
- Full/Half Duplex
- Auto MDI/MDI-X Connection
- 4Mbits Packet Buffer Size
- 8K MAC Address Table
- 10K Jumbo Packets
- IEEE 802.3af/at PoE+
- Advanced PoE Functions: Output Setting, Smart PoE, PoE Scheduling and Budget Management
- Web GUI / CLI / NMS Management
- Redundant Network with STP/RSTP/ERPSv2
- RADIUS, IEEE 802.1X, SNMPv3, HTTPs, SSH
- 5 Year Warranty
-
73208MP-BT SERIES 7 - INDUSTRIAL MANAGED 8 PORT GIGABIT POE++ SWITCH WITH 2 SFP PORTS
04 Mar 2025 SilverNet- IEEE803.af/at/bt compliant
- RJ45 supports auto MDI/MDI-X function
- Auto negotiation speed, half/full-duplex
- Store and forward
- Reverse polarity protection
- Resettable fuse to protect against overcurrent
- IP-40 protection
- EFT protection for power line
- Ethernet ESD protection
- DIN rail and Wall mounted installation
-
73816MP-10G SERIES 7 - INDUSTRIAL MANAGED 16 PORT ETHERNET 12 PORT SFP 4 PORT 10G SFP+ LAYER 2 SWITCH
04 Mar 2025 SilverNet- 16 x 10/100/1000Base T
- 8 x 1000Base FX SFP slots + 4 x 10G SFP+
- 56Gbps Backplane bandwidth
- IEEE803.af/at compliant
- RJ45 supports auto MDI/MDI X function
- Auto negotiation speed, half/full duplex
- Store and forward
- Max packet size: 10K bytes
- MAC address size: 16K
- Wide range power design (9~56VDC)
- Operating temperature (40 C ~+75 C)
- Resettable fuse to protect against overcurrent
- Reverse Polarity Protection
- DIN Rail or wall mountable
- EFT protection for power line
- Ethernet ESD protection
- IP40
-
- 24 x 10/100/1000M Base TX RJ45 Ports
- 4 xGigabit Combo (SFP/RJ45) Ports
- Auto Negotiation
- Full/Half Duplex
- Auto MDI/MDI X Connection-
- 4Mbits Packet Buffer Size-
- 8K MAC Address Table-
- 10K Jumbo Packets
- IEEE 802.3af/at PoE+
- Advanced PoE Functions: Output Setting, Smart PoE, PoE Scheduling and Budget Management
- Web GUI / CLI / NMS Management
- Redundant Network with STP/RSTP/ERPSv2
- RADIUS, IEEE 802.1X, SNMPv3, HTTPs, SSH
- 5 Year Warranty
-
- 16 x SFP, 8 x RJ45 / SFP Combo, 4 x 10G SFP+ Ports
- Up to 12Mbit Cache, supporting up to 4k Video Traffic
- 128Gbps Bandwidth
- 10Kbytes Maximum Packet Length
- 16K MAC Address Table
- Store and Forward (Full/Half Duplex Mode)
- <7μs Response Time
- Dual Redundant Power Supply
- Wide range power design (15~56VDC)
- Operating temperature (-40°C ~+75°C)
- Overcurrent Protection
- Reverse Polarity Protection
- Ethernet ESD protection
- IP40
- High Strength Metal Enclosure
